How to Feed-through terminal

Feed-through terminal blocks are essential components in modern electrical installations, designed to streamline wiring tasks while ensuring secure, efficient, and organized power distribution. The JHPTX series, developed by JINH, represents a high-performance range of DIN rail-mounted Feed-through terminals for various industrial and commercial wiring applications.

---

How to Use a Feed-through Terminal

• Mount the block on a standard DIN rail using the integrated rail clip.
• Strip the wire insulation according to the recommended length (typically 8–10mm).
• Insert the conductor into the terminal port; the internal copper bar ensures strong electrical contact.
• Secure the spring-loaded clamp to fix the wire.
• Repeat the process for output terminals. Each Feed-through terminal offers in-and-out wire access, ensuring a clean, linear connection path.

This streamlined method makes wiring quick and tool-friendly, ideal for large-scale cabinet installations or space-constrained environments.



Product Functions and Advantages

The JHPTX Feed-through terminal is engineered to meet the demands of high-current and high-voltage applications while maintaining a compact structure. Its main features include:

• Durable PA66 housing: Flame-retardant, high-temperature resistant, and impact-resistant.
• Tin-plated brass conductor bar: Provides superior conductivity and corrosion resistance.
• Multiple configurations: Available in 6, 12, or 18 port models to suit different wiring layouts.
• DIN rail mountable: Simplifies installation and ensures a secure mechanical fit.
• Compact design: Saves panel space without sacrificing performance.
• Secure screw connection: Ensures strong grip, minimizes contact resistance, and improves circuit reliability.

The Feed-through terminal allows for high-current input (up to 41A) and multiple output connections (typically 24A per port), providing excellent flexibility for circuit branching or power splitting.

Application Scenarios

Feed-through terminals like the JHPTX series are widely used across industries due to their reliability, modularity, and ease of use:

• Industrial control panels: Distribute control signals or power to relays, contactors, and PLCs.
• Lighting systems: Enable fast, organized wiring for commercial and architectural lighting projects.
• Power distribution cabinets: Route main input power to multiple sub-circuits while maintaining clear wiring paths.
• Smart home installations: Ideal for structured and scalable power layout in residential automation.
• HVAC and automation: Secure connections in systems subject to vibration or heat.

Whether it’s for machine wiring or structured building systems, the JHPTX Feed-through terminal simplifies the process and enhances the system’s durability and safety.



Conclusion

The JHPTX series Feed-through terminal blocks from JINH deliver the reliability and flexibility required in today’s demanding electrical systems. Designed for fast installation and long-term performance, these terminals support a wide range of wire sizes and current capacities while keeping your wiring neat and efficient.

From industrial factories to commercial buildings and smart homes, the Feed-through terminal proves to be an essential solution for structured and secure power distribution. For any project that demands quality and speed, upgrading to JINH Feed-through terminals is a smart investment.
